Tungsten Smart-Heat™ Gas

Tungsten Smart-Heat™ Gas – Robust gas heater for harsh environments

Are you looking for raw infrared heating with an industrial design that can withstand both wind and weather?
Bromic Tungsten Smart-Heat™ Gas is built to deliver maximum heating power in professional outdoor environments such as restaurants, rooftop terraces and entrances – while also resisting weather and wear.

Thanks to an open, industrial honeycomb design and closed burner, it creates targeted, even infrared heat even in wind speeds of up to 15 km/h.

The model is available in two sizes:

• Gas 300 – covers up to 15 m²
• Gas 500 – covers up to 20 m²

Advantages of Tungsten Gas:

• Powerful infrared heating – ideal for open spaces
• Wind resistant up to 15 km/h
• Robust metal body & industrial design
• Closed burner – extended service life
• Adjustable heating direction (angled bracket)
• Easy installation – wall or ceiling
• Power connection required only for ignition & control
• Choose between Natural Gas (NG) or LPG

Technical specifications:

Gas 300

Power: 26 MJ (approx. 7.3 kW)
Coverage: approx. 15 m²
Dimensions (L x H x D): 427 x 420 x 447 mm
Gas flow NG: 0.57 m³/h
Gas flow LPG: 0.51 kg/h

Gas 500

Power: 43 MJ (approx. 12 kW)
Coverage: approx. 20 m²
Dimensions (L x H x D): 647 x 420 x 447 mm
Gas flow NG: 1.02 m³/h
Gas flow LPG: 0.93 kg/h

In common:

• Power supply: 220–240 V / 1.5 A
• Material: Weatherproof metal
• Color: Matte black
• IP class: IPX4
• Certification: UKCA – tested by Intertek

Assembly & control:

Installation:

• Wall mounting (wall bracket included)
• Ceiling mounting (pendant tube – optional)
• Heat shield recommended for low ceiling heights

Steering options:

• On/Off
• Manual wall switch
• Dimmer (Affinity – optional)

Minimum installation height:

• Wall: 2000 mm
• Roof: 2500 mm (without deflector), 2600 mm (with deflector)

Recommended for:

• Large outdoor cafes & restaurants
• Commercial roof terraces & entrances
• Sports facilities & spas
• Public environments with high traffic
• Projects where power, sustainability & operational reliability are required
